Descripción
- Sensor Type: Uncooled VOx(vanadium oxide)
- Resolution(pixel) 640*512
- Pixel Size(µm) 12*12
- NETD(mK) ≤20 mK（0.02℃）
- Frame rate(Hz) 50
- Detection distance(m) 1800
- Objective Lens(mm) 35
- Optical Magnification(x) 2.2
- Digital Zoom(x) 2/4/6/8
- Field of view (Horizontal) 12.5°
- Field of view (Vertical) 10.0°
- Field of view (Diagonal) 16.0°
- Eye Relief(mm) 20
- Diopter Adjustment(D) -5~5
- Display Type: AMOLED
- Resolution(pixel) 1920*1080
- Scene Mode City/Rain/Forest
- Image mode WT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY
- Photo / Video
- Photo resolution(pixel) 1440*1080
- Photo Format .JPG
- Video Resolution(pixel) 1440*1080
- Video Format .mp4
- Storage(GB) Micro SD card (Max. 128GB)
- Image Engine Pard IREA
- Main function
- LRF detection range(m/yd) 1000/1200
- PIP Yes
- Gyroscope Yes
- Loop Recording Yes
- Hot Track Yes
- E-compass Yes
- Shutter Mechanical shutter
- Microphone Yes
- Firmware Upgrade Yes
- Connections
- USB Type-C Yes
- HDMI Output Yes
- WiFi Yes
- Supported Apps PardVision2
- Power Supply
- Battery Type Lithium Ion 18650*1
- Output Voltage(V) 3.7
- Operating time(h,max) ≤6
- External power supply(V) USB Type-C
- Environmental characteristic
- Degree of protection IP67
- Operating Temp(°C/°F) -30 ~ +55 / -22 ~ +131
- Material: Housing Aluminum Alloy+Composite
- Eyepiece All-glass multi-coated lens
- Product Dimension/with LRF(L * W * H, mm) 169*58*48
- N.W/pcs(with LRF&battery, g) 360
